HP DesignJet Printer (C1633B) C1633B
Status:
Available
Condition:
OEM
Your Price:
RFQ
Printer Parts
Printer Information
Related Models
Bail
C2858-60115 - Bail assembly - Has star wheel assemblies attached
Belt
1500-0855 - HP Designjet 600, 650C Motor Belt (Small belt).Y axis drive belt.
1500-0856 - Carriage belt for HP DesignJet 36inch size plotters.
Bracket
C2847-00051 - Y-tensioner bracket on left side plate
Brake
17072-40007 - Spindle Brake - Engages Right End of Rollfeed Spindle Rod
Cable
C1633-60050 - Carriage assembly trailing cable - 28-pin (F) connector to 28-pin (F) connector attached to mounting hardware - 1.6m (5.3ft) long
C2847-60019 - Ribbon cable - 5-pin (F) connector to 5-pin (F) connector - 40.3cm (15.9in) long
C2847-60034 - Ribbon cable - Has 12-pin (F) connectors - 1.2m (3.9ft) long
C2951A - IEEE-1284 Bi-Tronics parallel cable - DB-25 (M) connector (type A) to 36 pin Centronics (M) connector (type B) - 3.0m (9.8ft) long
5063-1256 - IEEE-1284 Bi-Tronics parallel cable - DB-25 (M) connector (type A) to 36-pin Centronics (M) connector (type B) - 2.0m (6.6ft) long
5063-1257 - IEEE 1284 Bi-Tronics parallel cable - DB-25 (M) connector (type A) to 36-pin Centronics (M) connector (type B) - 3.0m (9.8ft) long
17255D - RS-232C serial cable - 25-pin (M) to 25-pin (F) - 1.2m (3.9ft) long
24540-80010 - Centronics (parallel) cable - 36-pin (M) to 25-pin (M) - 2.0m (6.6ft) long
Cap
C2858-40043 - Spindle end cap - Small core spacer - Removes for loading the media roll. Please order spindle assembly.
C3172-40006 - Spindle end cap - Small core spacer - Removes for loading the media roll. Please order spindle assembly.
Carriage
C1633-60120 - Carriage assembly - Includes carriage PC board
Caster
1492-0145 - Lockable caster assembly - Includes stem and washer
Clip
C1633-40092 - Starwheel clip for HP DesignJet-C1633A
Control Panel
C2847-60087 - Control panel assembly - Includes ribbon cable
Cover
C1633-40047 - Right end cover - For end of upper stand (Chassis) assembly
C2847-60062 - Left end cover assembly - For end of upper stand (Chassis)
Cutter
C2858-60021 - Cutter mechanism assembly - Auto cutter for rollfeed paper
Fan
3160-0814 - Tubeaxial fan (Matsushita FBK-09A12M2-MOD) - 82.5mm (3.25in) mount hole spacing, 25.5mm (1.0in) thick, 12VDC, 35.3CFM
Film
51642A - Polyester matte film - 61cm (24in) x 36.6m (120ft) roll
51642B - Polyester matte film - 91.4cm (36in) x 36.6m (120ft) roll
51642C - Polyester matte film - B size (11 x 17-inches) - 40 sheets
51642G - Polyester Matte Film - D Size - 22 x 34 inches (40 Sheets)
51642J - Polyester matte film - Architectural D size (24 x 36-inches) - 40 sheets
51642K - Polyester matte film - E size (34 x 44-inches) - 40 sheets
51642N - Polyester matte film - Architectural E size (36 x 48-inches) - 40 sheets
51642F - Film (Matte) for DesignJet-C1633A, DesignJet 600, DesignJet 650, DesignJet 200 D size
51642H - Film (Matte) for DesignJet-C1633A, DesignJet 600, DesignJet 650, DesignJet 200 D size
Handle
C1633-40030 - Pinchwheel manual lift handle - Paper loading lever
Hinge
07575-40111 - Female half of hinge (on chassis) - For lift-up window
07575-40012 - Male half of hinge (on window) - For lift-up window
Holder
C1633-40094 - Holder - For 'Help' card and hand held cutter
IC ROM
1818-4932M - EEPROM - on Main Logic Board
C1633-18009 - High ROM (Revision 2.1) - Note: the 'High' and 'Low' ROMs MUST be the same revision
C1633-18008 - Low ROM (Revision 2.1) - Note: the 'High' and 'Low' ROMs MUST be the same revision
Kit
C2847-60061 - Hardware kit - Package of 6 screws for stand assembly
Label
C3195-00057 - Safety label - Provides warning that encoder strip is sharp
Leg
C2848-60002 - Leg assembly - Side support with foot bar and two casters
Lifter
C2858-60209 - Bail lift mechanism kit - Includes cam gear, engaging lever, engaging lever gear, engaging lever spring, Y-tensioner bracket, bail lift cam, cam gear support, screws, and washers
Manual
C1633-90000 - C1633A/B DesignJet plotter service manual
C1633-90041 - C1633B DesignJet plotter users guide
C6072-60281 - Toolbox and driver software - HP-GL/2 and RTL drivers for Windows 3.1/95/98/NT 4.0 (all DesignJets), and toolbox software for Windows 95/NT 4.0 (Only for DesignJet 430/450C/455CA/1050C/1055CM) - On 3.5-inch 1.44MB floppy disks (English)
5959-9733 - Manual for Designjet 820 MFP Series, DesignJet-C1633A, DesignJet 600, DesignJet 650
C1633-90044 - C1633B DesignJet plotter users guide (German)
C1633-90048 - C1633B DesignJet plotter users guide (Japanese)
Media Bin
C1633-00019 - Media bin back - For top of wire rack below plotter
C1633-00020 - Media bin front - Main part of wire rack below plotter
C1633-00044 - Media bin adjust - Adjustable media bottom stop in wire rack
Memory
C2065A - 4MB, 80nS, 36-bit SIMM memory module - For HP Plotters, LaserJet IIISi, 4/4M, 4Si/MX and other models.
D2150-69001 - 1MB, 80nS, 36-bit SIMM memory module
Module
J2382-69003 - External JetDirect LAN interface module with EtherTwist (10Base-T) and ThinLAN (10Base-2) connectors
J2590-69001 - External JetDirect LAN interface module with RJ-45 connector for EtherTwist (10Base-T) or 100VG/802.12 input and three parallel (DB-25) output connectors
J2592-69001 - External JetDirect LAN interface module with EtherTwist (10Base-T) connector
J4102-61021 - External JetDirect LAN interface module with EtherTwist (10Base-T) connector
J4102-69022 - External JetDirect LAN interface module with EtherTwist (10Base-T) connector
Motor
C2848-60003 - Motor/encoder assembly (includes helical drive gear) - 'X' axis drive - NOTE: motor and gear are only sold as a set
C2847-60221 - Motor assembly - Includes power cable
3140-0854 - Stepper motor for HP DesignJet 600 D size
Overlay
C1633-60040 - Control panel overlay (Japanese)
C1633-60041 - Control panel overlay (German)
C1633-60042 - Control panel overlay (French)
C1633-60043 - Control panel overlay (Italian)
C1633-60044 - Control panel overlay (Spanish)
C1633-60045 - Control Panel Overlay (English)
Packaging
C3196-60113 - Repackaging Kit - for Main Plotter Unit
Paper
C1860A - HP Bright white InkJet paper - 61cm (24in) x 45.7m (150ft) roll
C3850A - Opaque bond paper - 91.4cm (36in) x 45.7m (150ft) roll
C3851A - Opaque bond paper - 61cm (24in) x 45.7m (150ft) roll
C3854A - Opaque bond paper - Architectural E size (36 x 48-inches) - 100 sheets
C3855A - Bright White Inkjet Paper - 61cm (24in) x 45.7m (150ft) roll
C6036A - Bright white InkJet paper - 91.4cm (36in) x 45.7m (150ft) roll
PC Board
C1633-68103M - (Ink) drop sense board
C1633-68105M - Interconnect board
C1633-69101 - Main Logic Board
0950-2417 - Power supply board
Pinch Assembly
C1633-60039 - Pincharm assembly - Curved black plastic plate with four small rubber rollers - Does NOT include spring or bushing
Plate
C1633-00053 - SIMM Plate - Covers Access to SIMM Slot Connectors
Power Cord
8120-4211 - Power cord (Mint Gray) - 17 AWG, 2.0m (6.6ft) long - Has straight (F) receptacle (for 240V in South Africa and India)
Power Module
0957-2340 - Wall mount power supply module - 120VAC input 60Hz power supply AC DC 15W UNIVERSAL ADAPTER Power module (wall mount)- Input voltage 100-240 VAC - Output voltage 12 VDC, 15 watts output, 1.0A - for Jet Direct power and other accessories.
0957-2481 - Pwra brk uni 12vdc 15w
Power Supply
0950-2623 - Switching power supply (Delta DPS-158ABA) - 100-240VAC input, 47-63Hz - Four DC outputs (5.15V, +12V, -12V, 24V) - 158 watts - Includes upgrade sticker
Pulley
C3170-60009 - Reduction pulley - Includes 2 Bearings Shaft (0.16in Diameter on Both Ends) Flange Pulley and Instructions
Roller
C4700-60042 - Paper drive (platen) roller assembly - Long gear driven roller - Includes roller and mark encoder
Sensor
C2847-60021 - Media sensor assembly - Includes cable
C2847-60022 - Pincharm sensor - Includes cable
Software
C6072-60284 - Toolbox and driver software - HP-GL/2 and RTL drivers for Windows 3.1/95/98/NT 4.0 (all DesignJets), and toolbox software for Windows 95/NT 4.0 (Only for DesignJet 430/450C/455CA/1050C/1055CM) - On 3.5-inch 1.44MB floppy disks (German)
C6072-60285 - Toolbox and driver software - HP-GL/2 and RTL drivers for Windows 3.1/95/98/NT 4.0 (all DesignJets), and toolbox software for Windows 95/NT 4.0 (Only for DesignJet 430/450C/455CA/1050C/1055CM) - On 3.5-inch 1.44MB floppy disks (French)
C6072-60286 - Toolbox and driver software - HP-GL/2 and RTL drivers for Windows 3.1/95/98/NT 4.0 (all DesignJets), and toolbox software for Windows 95/NT 4.0 (Only for DesignJet 430/450C/455CA/1050C/1055CM) - On 3.5-inch 1.44MB floppy disks (Spanish)
C6072-60287 - Toolbox and driver software - HP-GL/2 and RTL drivers for Windows 3.1/95/98/NT 4.0 (all DesignJets), and toolbox software for Windows 95/NT 4.0 (Only for DesignJet 430/450C/455CA/1050C/1055CM) - On 3.5-inch 1.44MB floppy disks (Italian)
Spindle
C2848-60011 - Rollfeed spindle rod assembly (E-size 36 inch ) - Includes spindle and end caps
Starwheel
C1633-60051 - Starwheel assembly - Small plastic wheel with metal teeth
Strip
C4714-60098 - Encoder strip assembly (E-size) - Includes encoder strip and encoder strip spring
Switch
C2847-60044 - Power switch assembly - Includes cable
Window
C1633-40075 - Lift-up viewing window (Clear)
HP DesignJet Printer (C1633B)
Manufacture:
HP
MPN:
C1633B
Description:
HP DesignJet Printer (C1633B)
Condition:
OEM
Warranty:
1 year warranty with OEM supplies from the manufacture.
Product Options:
OEM is not available
Image/s:
This product does not have an image.
Product Tags:
C1633B
Plotter C1633B
CB506-67901
HP
