RM1-5737-000CN | Multipurpose/tray 1 sensor cable assembly - For duplex models only |
RM1-5740-000CN | Sensor cable assembly |
RM1-5741-000CN | Sensor cable assembly |
RM1-5742-000CN | Lifter cable assembly |
8120-8909 | Telephone cable - 3.0m (9.8ft) long (Black) - RJ-11 plug on one end (Austria) |
8120-8913 | Telephone cable - 3.0m (9.8ft) long (Black) - RJ-11 plug on one end (Israel) |
8120-8914 | Telephone cable - 3.0m (9.8ft) long (Black) - RJ-11 plug on one end (Italy) |
8120-8918 | Telephone cable - 3.0m (9.8ft) long (Black) - RJ-11 plug on one end (Sweden) |
8120-8911 | Telephone cable - 3.0m (9.8ft) long (Black) - RJ-11 plug on one end (Denmark) |
8120-8920 | Telephone cable - 3.0m (9.8ft) long (Black) - RJ-11 plug on one end (Turkey) |
8120-8907 | Telephone cable (Australian) - 3.0m (9.8ft) long (Gray) - RJ-11 plug on one end, Australian phone plug on other end |
8120-8908 | Telephone cable (Korea) - 3.0m (9.8ft) long (Gray) - RJ-11 plug on one end, Korea phone plug on other end |
8120-8921 | Telephone cable (five conductor) - RJ-11 (M) to BS-601A (M/F) - 3m (9.8ft) long (for the U.K., New Zealand, and Hong Kong) |
8120-8922 | Telephone cable - 3.0m (9.8ft) long (Black) - RJ-11 phone plug connectors (Eastern Europe, Czechoslovakia, Slovenia, and Hungary) |
8121-0844 | Telephone cable with bill tone filter - 3.0m (9.8ft) long (Black) - RJ-11 plug on one end (Switzerland) |
8121-0811 | Telephone cable (2-wire) - RJ11 (M) connectors - 3m (10ft) long (USA, Canada, Mexico, Latin America, Greece, Poland, Saudi Arabia, Portugal, and Spain) |
RM1-1638-000CN | Sensor cable - From DC Controller board to sensors SR1, SR2 and SR3 |
RM1-1644-000CN | Sensor cable - Between DC Controller board and disengaging drive sensor |
RM1-5746-000CN | Cartridge fan (FM2) cable assembly |
RK2-2506-000CN | Scanner flat flexible cable (FFC) - Connects the laser scanner connector (J110) to the DC controller board through (J501) |
RK2-2508-000CN | Scanner flat flexible cable (FFC) - Connects the laser scanner connector (J111) to the DC controller board through (J503) |
RM1-5714-000CN | Fusing connecting cable assembly |
RM1-5718-000CN | Interlock switch (SW3) cable assembly |
RM1-5719-000CN | Connecting cable assembly - Connects the 24V interlock switch (SW3) with the low voltage power supply (LVPS) PCA |
RM1-5721-000CN | Rear cable assembly - Connects the DC controller board with the upper high voltage power supply |
RM1-5723-000CN | Front cable assembly - Connects the fuser functions with the DC controller PCA |
RM1-5730-000CN | Duplexing unit cable assembly |
RM1-5731-000CN | Pick-up motor (M13) cable assembly |
RM1-5750-000CN | Present sensor cable assembly - For the multi-purpose/tray 1 (simplex models only) |
RM1-5752-000CN | Motor/sensor cable assembly |
RM1-5749-000CN | Connecting cable assembly |
RM1-1628-000CN | Motor cable - From DC Controller to all four drum motor assemblies |
RM1-5743-000CN | Control panel cable assembly |
RM1-1629-000CN | Sensor cable assembly |
RM1-1640-000CN | Control panel cable |
RM1-1646-000CN | Fan cable assembly - From DC Controller board to Fans 1 through 4 |
RM1-1653-000CN | Memory contact cable - Connects to e-label sensors |
RM1-1633-000CN | Paper pickup cable - From DC Controller to several connections in paper pickup area including paper size sensors |
RM1-1641-000CN | Paper sensor cable - Between DC Controller and cassette paper sensor |
RM1-1643-000CN | Door switch cable assembly |
5063-1255 | IEEE 1284 Bi-Tronics parallel cable - DB-25 (M) connector (type A) to 36-pin high density IEEE 1284C (M) connector (type C) - 10m (33ft) long mini-connector. |
RK2-3941-000CN | Laser/scanner flat flexible cable |
RK2-3943-000CN | Scanner laser flat cable - Connects the scanner to the DC controller PC board |
5851-3499 | Cable Fax NOT AVAIL FOR REPLMNT |
CF116-60105 | Assy-Control Panel Photon Cable |
RM1-5497-010CN | Cooling fan - Provides air to the cartridge area |
RM1-8065-000CN | Switch cable assembly |
RM1-8084-000CN | Rear cable assembly |
