RF5-3682-000CN | Rear paper guide - Width adjustable side wall for documents placed in the ADF input tray - Mounts on top of the ADF base assembly |
RF5-3698-000CN | Front paper guide - Width adjustable side wall for documents placed in the ADF input tray - Mounts on top of the ADF base assembly |
RB2-8681-000CN | Lower internal cable guide (I/F 5) - One of six pieces that form the pivioting cable guide from the ADF assembly to the scanner assembly - Mounts on the left rear of the ADF assembly |
RB2-8682-000CN | Upper internal cable guide (I/F 6) - Arm shaped ribbon cable retainer - One of six pieces that form the pivioting cable guide from the ADF assembly to the scanner assembly - Mounts on the left rear of the ADF assembly |
RB2-8047-000CN | Upper front cable guide (I/F 4) - Curved plastic piece - One of six pieces that form the pivioting cable guide from the ADF assembly to the scanner assembly - Mounts on the left rear of the ADF assembly |
RB2-6541-000CN | Paper guide for HP LaserJet 9040 9050 Series |
RG5-5654-000CN | Transfer roller guide - Mounts to the top of the base structure of the transfer roller assembly |
RG5-5651-030CN | Transfer guide assembly (Ribbed plastic piece) - Has slot for the transfer roller assembly |
RG5-6313-030CN | Upper and lower rear cable guides (I/F 2 and 3) - Two of six pieces that form the pivioting cable guide from the ADF assembly to the scanner assembly - Mounts on the left rear of the ADF assembly |
RG5-6311-000CN | Cable guide assembly - Black plastic channel/cover - Mounts on the rear of the ADF main assembly |
4B1-0626-000CN | Paper guide wire-form - Large 'U' shaped paper guide that locks on the back of the paper flipper assembly |
C8085-60528 | Alignment Rod Guide kit - Blue plastic slider on alignment rod - Snaps into bottom of printer to locate alignment rod - Also includes metal ground contact piece between guide bar and printer chassis - Does not include rod |
C8085-60535 | Guide Bar Kit - Grey plastic piece with four curved fingers to guide paper - Kit includes accumulator, two screws and instructions |
RB2-5522-000CN | Paper pickup guide - Plastic shaft with several fins on it - Mounts on the upper right side of the print engine frame assembly |
RB2-5526-000CN | Cartridge guide - Plastic structure with cartridge guide slot molded into it - Mounts on the upper front side of the registration assembly |
Q5693-60527 | Paper guide (nose piece) - Input paper guide to the mailbox assembly - Inserts into the output slot of the printer |
